 液体窒素生物試料保存容器 LN2 Refrigerator Dewar Group |
|
IC-3R |
IC-6R |
IC-10R |
IC-20R |
IC-20RX |
Arctic 22R |
Arctic 22RX |
| LN2 Capacity (liters) |
3.6 |
6 |
10 |
20 |
20 |
22 |
22 |
| Static Hold Time (days)* |
25 |
30 |
100 |
200 |
105 |
146 |
146 |
Evaporation Rate*
liters/day |
.14 |
.20 |
.10 |
.10 |
.19 |
.15 |
.15 |
Working Time**
days / weeks |
14 /
2 |
18 /
3 |
62 /
9 |
126 /
18 |
65 /
9 |
112 /
16 |
112 /
16 |
| Necktube Diameter |
2.25″ /
57mm |
2.25″ /
57mm |
2.25″ /
57mm |
2.25″ /
57mm |
3.75″ /
95mm |
2.62″ /
66mm |
2.62″ /
66mm |
| Outside Diameter |
8.75″ /
222mm |
8.75″ /
222mm |
11.25″ /
286mm |
15.00″ /
381mm |
15.00″ /
381mm |
15.00″ /
381mm |
15.00″ /
381mm |
| Overall Height |
16.5″ /
419mm |
18.10″ /
460mm |
23.00″ /
584mm |
25.50″ /
647mm |
25.50″ /
647mm |
26.25″ /
667mm |
26.25″ /
667mm |
| Empty Weight |
7 lbs /
3.5 kg |
7 lbs /
3.5 kg |
12 lbs /
5.5 kg |
23 lbs /
11.5 kg |
23 lbs /
10.5 kg |
22 lbs /
10 kg |
22 lbs /
10 kg |
| Full Weight |
14 lbs /
6.5 kg |
18 lbs /
8.5 kg |
33 lbs /
15 kg |
60 lbs /
27.5 kg |
60 lbs /
27.5 kg |
62 lbs /
28.5 kg |
62 lbs /
28.5 kg |
| Canister Length |
5″ /
127mm |
5″ /
127mm |
11″ /
279mm |
11″ /
279mm |
11″ /
279mm |
11″ /
279mm |
11″ /
279mm |
| Canister Inside Diameter |
1.75″ /
44mm |
1.75″ /
44mm |
1.75″ /
44mm |
1.75″ /
44mm |
2.96″ /
75mm |
2.00″ /
51mm |
2.00″ /
51mm |
| Canisters |
6 |
6 |
6 |
6 |
6 |
3 |
6 |
Capacity:
0.5cc straws (on canes)
0.5cc straws (bulk)
1.2 ml. vials |
330
990
n/a |
330
990
n/a |
660
1,800
180 |
660
1,800
180 |
2,340
5,820
660 |
480
1,356
205 |
960
2,712
410 |
|
|
| LN2 Capacity (liters) |
| Static Hold Time (days)* |
Evaporation Rate*
liters/day |
Working Time**
days / weeks |
| Necktube Diameter |
| Outside Diameter |
| Overall Height |
| Empty Weight |
| Full Weight |
| Canister Length |
| Canister Inside Diameter |
| Canisters |
Capacity:
0.5cc straws (on canes)
0.5cc straws (bulk)
1.2 ml. vials |
|
IC-35R |
IC-35RX |
IC-38RX/6 |
IC-38RX/10 |
IC-50RX |
| 35 |
35 |
38 |
38 |
50 |
| 269 |
184 |
135 |
135 |
125 |
| .13 |
.19 |
.28 |
.28 |
.40 |
168 /
24 |
112 /
16 |
84 /
12 |
84 /
12 |
78 /
11 |
2.25″ /
57mm |
3.75″ /
95mm |
5.00″ /
127mm |
5.00″ /
127mm |
3.75″ /
95mm |
18.50″ /
470mm |
18.50″ /
470mm |
18.50″ /
470mm |
18.50″ /
470mm |
18.50″ /
470mm |
26.00″ /
660mm |
26.00″ /
660mm |
27.50″ /
698mm |
27.50″ /
698mm |
30.75″ /
781mm |
31 lbs /
14.5 kg |
31 lbs /
14.5 kg |
31 lbs /
14.5 kg |
31 lbs /
14.5 kg |
38 lbs /
17.5 kg |
94 lbs /
43 kg |
94 lbs /
43 kg |
102 lbs /
46.5 kg |
102 lbs /
46.5 kg |
128 lbs /
58.5 kg |
11″ /
279mm |
11″ /
279mm |
11″ /
279mm |
11″ /
279mm |
11″ /
279mm |
1.75″ /
44mm |
2.96″ /
75mm |
4.1″ /
104mm |
2.96″ /
75mm |
2.96″ /
75mm |
| 6 |
6 |
6 |
10 |
6 |
660
1,800
180 |
2,340
5,820
660 |
4,680
10,320
1,320 |
3,900
9,700
1,100 |
2,340
5,820
660 |
|
|
|
 液体窒素生物試料運搬容器 Nitrogen Vapor Shipping Vessels |
|
|
IC-2VS |
IC-4VS |
IC-7VS |
IC-20VS |
| LN2 Capacity (liters) |
2.4 |
4.6 |
6.0 |
6.3 |
| Static Hold Time (days)* |
17 |
32 |
26 |
28 |
Evaporation Rate*
liters/day |
.14 |
.14 |
.23 |
.22 |
Working Time**
days / weeks |
2.25″ /
57mm |
2.25″ /
57mm |
3.75″ /
95mm |
3.75″ /
95mm |
| Necktube Diameter |
8.75″ /
222mm |
8.75″ /
222mm |
11.25″ /
286mm |
15.00″ /
381mm |
| Outside Diameter |
16.375″ /
416mm |
20.375″ /
517mm |
20.125″ /
511mm |
30.0″ /
762mm |
| Overall Height |
8 lbs /
4 kg |
11 lbs /
5 kg |
15 lbs /
7 kg |
29.5 lbs /
13.5 kg |
| Empty Weight |
12.4 lbs /
5.5 kg |
19.0 lbs /
9 kg |
25.0 lbs /
11.5 kg |
40.0 lbs /
18.5 kg |
| Full Weight |
5″ /
127mm |
11″ /
279mm |
11″ /
279mm |
11″ /
279mm |
| Canister Length |
1.75″ /
44mm |
1.75″ /
44mm |
2.96″ /
75mm |
2.96″ /
75mm |
| Canisters |
1 |
1 |
1 |
7 |
Capacity:
0.5cc straws (on canes)
0.5cc straws (bulk)
1.2 ml. vials |
55
165
n/a |
110
300
30 |
390
969
110 |
2730
6789
770 |
|
|
| 長期保存型液体窒素生物試料容器 Inventory Racking System |
|
D-4000 |
D-2000C |
| LN2 Capacity (liters) |
120 |
60 |
| Static Hold Time (days) |
150 |
83 |
Evaporation Rate
liters/day |
.80 |
.72 |
| Necktube Diameter |
8.5″ / 216mm |
8.5″ / 216mm |
| Overall Height |
38″ / 965mm |
28″ / 711mm |
| Outside Diameter |
22″ / 559mm |
22″ / 559mm |
| Empty Weight |
71 lbs / 32.5 kg |
55 lbs / 25 kg |
| Full Weight |
285 lbs / 129.5 kg |
163 lbs / 74 kg |
| Racks |
4 |
4 |
| 2″ High Boxes Per Rack |
10 |
5 |
| Box Dimensions |
5.25″ x 5.25″ 133mm x 133mm |
5.25″ x 5.25″ 133mm x 133mm |
| Ampules Per Box |
100 |
100 |
| Boxes Per Vessel |
40 |
20 |
| Capacity: Ampules in Boxes (1.2 or 2.0 ml) |
4,000 |
2,000 |
|
